Pneumatic Air Regulator | AR

The function of the Pneumatic Air Regulator is to regulate the pressure of the compressed air source entering the pneumatic system in order to maintain the stable pressure of the pneumatic working system. Its function is to set the output pressure, that is, Pressure Regulating Valve. The pressure characteristic of Pneumatic Air Regulator is that the output pressure is always lower than the input pressure, that is to say, the pressure is reduced. It is usually installed at the compressed air inlet of the pneumatic system (There are also closely connected air filters on the input front end.).

There are many kinds of Pneumatic Air Regulator. They are divided into direct-acting type Pneumatic Air Regulator and pilot type Pneumatic Air Regulator according to decompression method.

Pneumatic Air Regulator AW

AW Air Regulator can save space, required pipes is fewer, and saves installation costs. Pneumatic Air Regulator AR is made of solid material that can withstand high pressure and allows the user to operate a wide range of regulating pressure.

Working Medium: Compressed Air
Proof Pressure: 1.5MPa
Ambient temperature: 5~60℃
Filtration aperture: 40μm(routine) or 5μm(customized)
Range of pressure regulation: 0.05~0.7MPa(AW1000-02); 0.05~0.85MPa
Learn more
Pneumatic Air Regulator AW (Overflow Type)

AW Air Regulator With Overflow can save space, required pipes is fewer, and saves installation costs. Pneumatic Air Regulator AR is made of solid material that can withstand high pressure and allows the user to operate a wide range of regulating pressure.

Working Medium: Compressed Air
Proof Pressure: 1.0MPa
Ambient temperature: 5~60℃
Filtration aperture: 40μm(routine) or 5μm(customized)
Range of pressure regulation: 0.05~0.85MPa
Learn more
Pneumatic Air Regulator AFR/BFR

A/B Series Air Combination save space and piping, facilitate maintenance and centralized management. Different combination modes can be selected according to the needs, and different filter cups and filtering accuracy can be selected.

Working Medium: Compressed Air
Proof Pressure: 1.5MPa
Ambient temperature: 5~60℃
Filtration aperture: 40μm(routine) or 5μm(customized)
Range of pressure regulation: 0.05~0.85MPa
Learn more
Pneumatic Air Regulator FR

FR Air Regulator is a small, low cost, high performance pressure regulator. Pneumatic Air Regulator AR can be used in pneumatic instruments, controllers, pneumatic chucks, actuators, and other aspects, and has a variety of installation forms.

Working Medium: Compressed Air
Proof Pressure: 1.6MPa
Ambient temperature: 5~60℃
Filtration aperture: 40μm(routine) or 5μm(customized)
Range of pressure regulation: 0.05~1.2MPa
Learn more
Pneumatic Air Regulator F

Pressure Regulating Filter F Series is a filter pressure reducing valve which adopts more commonly used port size G1/4. Not only effectively filter out the solid particles and moisture in the air source, but also realize the function of pressure regulation.

Working Medium: Compressed Air
Proof Pressure: 1.5MPa
Ambient temperature: 0~60℃
Filtration aperture: 40μm(routine) or 5μm(customized)
Range of pressure regulation: 0.05~1.2MPa
Learn more
Pneumatic Air Regulator GFR

Pneumatic Air Regulator AR use embedded type square pressure gauge, saving installation space. There are three forms of drainage, such as manual, differential pressure and automatic drainage.

Working Medium: Compressed Air
Proof Pressure: 1.5MPa
Ambient temperature: -20~70℃
Filtration aperture: 40μm(routine) or 5μm(customized)
Range of pressure regulation: 0.05~0.85MPa
Learn more
Pneumatic Air Regulator NFR (Explosion-proof)

NFR Explosion Proof Air Combination can regulate the air source to keep the air source in a constant state, which can reduce the damage the valve or actuator and other hardware due to the sudden change of the air source pressure.

Working Medium: Compressed Air
Proof Pressure: 1.5MPa
Ambient temperature: 5~60℃
Filtration aperture: 40μm(routine) or 5μm(customized)
Max. adjustable pressure: 1.0MPa
Learn more
Pneumatic Air Regulator SFR

SFR Air Regulator can regulate the air source to keep the air source in a constant state, which can reduce the damage the valve or actuator and other hardware due to the sudden change of the air source pressure.

Working Medium: Compressed Air
Proof Pressure: 1.5MPa
Ambient temperature: 5~60℃
Filtration aperture: 40μm(routine) or 5μm(customized)
Max. adjustable pressure: 0.85MPa
Learn more
Mini Pneumatic Air Regulator FR500A

Miniature Air Filter Regulator can regulate the air source to keep the air source in a constant state, which can reduce the damage the valve or actuator and other hardware due to the sudden change of the air source pressure.

Working Medium: Compressed Air
Proof Pressure: 1.0MPa
Ambient temperature: -10~60℃
Filtration aperture: 40μm(routine) or 5μm(customized)
Range of pressure regulation: 0.05~0.8MPa
Learn more
