Overview for Pneumatic Air Lubricator Oil Sprayer RB/RBC
The easiest way to improve production quality is to increase the operating speed of the machine, but the result will cause excessive vibration noise, damage to the machine and product, and rapid damage to the production machine and other shortcomings, and because of the excessive impact force, the security will be greatly reduced and irreparable losses will be caused.
II. product advantages
1. Improve production efficiency
2. Extend mechanical life
3. Simplify mechanical design
4. Reduce maintenance costs
5. Reduce vibration noise
Technical Parameters for Pneumatic Air Lubricator Oil Sprayer RB/RBC
Maximum absorption energy(kgf·m): 0.3~15
Absorption stroke(mm): 6,7,12,15,25
Max. impact speed(mm): 5
Ambient temperature: -10~80℃
Technical Parameter for Pneumatic Air Lubricator Oil Sprayer RB/RBC Series
| Model |
Specification |
| Basic type |
Rubber pad |
Maximum absorption energy
(kgf·m) |
Absorption stroke
(mm) |
Max. impact speed
(mm) |
Max. operating frequency
(times/min) |
Ambient temperature |
Spring force (kgf) |
Weight
(gf) |
| Extend |
Return |
| RB0806S |
RBC0806S |
0.3 |
6 |
5 |
80 |
-10~80℃ |
0.35 |
0.75 |
15 |
| RB1007S |
RBC1007S |
0.6 |
7 |
70 |
0.65 |
0.96 |
25 |
| RB1412S |
RBC1412S |
2 |
12 |
45 |
0.70 |
1.63 |
65 |
| RB2015S |
RBC2015S |
6 |
15 |
25 |
0.85 |
2.09 |
150 |
| RB2725S |
RBC2725S |
15 |
25 |
10 |
0.90 |
2.04 |
360 |
Overall Dimension for Pneumatic Air Lubricator Oil Sprayer RB/RBC Series
| Model |
Basic type |
Rubber pad |
Hexagon nut |
| Basic type |
Rubber pad |
ΦD |
ΦE1 |
ΦE2 |
F |
H |
a |
L |
LL |
MM |
S |
ΦE1 |
LL |
Z |
B |
C |
h |
| RB0806 |
RBC0806 |
2.8 |
6.8 |
6.8 |
2.4 |
6 |
1.4 |
33.2 |
46.6 |
M8×1.0 |
40.6 |
6.8 |
57.1 |
10.5 |
12 |
13.9 |
4 |
| RB1007 |
RBC1007 |
3 |
8.6 |
8.6 |
2.7 |
7 |
1.4 |
39 |
53.7 |
M10×1.0 |
46.7 |
8.0 |
63.7 |
10 |
14 |
16.2 |
4 |
| Model |
Basic type |
Rubber pad |
Hexagon nut |
| Basic type |
Rubber pad |
ΦD |
ΦE1 |
ΦE2 |
F |
H |
K |
L |
LL |
MM |
S |
ΦE1 |
LL |
Z |
B |
C |
h |
| RB1412 |
RBC1412 |
5 |
12.2 |
12 |
3.5 |
12 |
12 |
58.2 |
79.3 |
M14×1.5 |
67.3 |
12 |
92.8 |
13.5 |
19 |
21.9 |
6 |
| RB2015 |
RBC2015 |
6 |
18.2 |
18 |
4 |
18 |
18 |
62.2 |
88.2 |
M20×1.5 |
73.2 |
18 |
105.2 |
7 |
27 |
31.2 |
6 |
| RB2725 |
RBC2725 |
8 |
25.2 |
25 |
5 |
25 |
25 |
86 |
124 |
M27×1.5 |
99 |
25 |
147 |
23 |
36 |
41.6 |
6 |
